die casting foundry molding machine

Main Products

sand molding machine

Micro-vibration compaction molding machines are commonly used molding equipment in foundry production. Their core working principle involves combining high-frequency micro-vibration with compaction to densify molding sand, thereby producing high-quality sand molds.

The advantage of sand casting molding machine as following:

1. High and uniform mold sand compaction

2. High molding efficiency

3. Suitable for various types of castings

4. Easy to operate with low labor intensity

5. Low energy consumption and controllable costs

6. Convenient equipment maintenance

Molding machine
Type	Z143W	Z144W	Z145W	Z146W	Z147W	Z148W	Z149W
flask size mm	400×400×100	500×400×180	500×400×200	600×500×200	700×550×200	800×700×350	1000×900×300
working table size mm	560×420	560×465	610×515	700×550	700×550	900×730	1170×830
outline size mm	1000×600×1420	1000×800×1420	1200×1000×1692	1380×850×1565	1380×850×1565	1309×1064×2240	140017002350
cylinder diameter mm	300	300	380	380	420	520	600

1. 40 years machines manufacturing and exporting.

2. Delivery within 30 days.
3. Safety wood or plywood crates packaging.
4. Full transportation insurance.
5. Sell to 126 countries on 6 continents.

>> AFTER SERVICES FOR THE PRESS
1. The above machines are all passed inspection of 3~5 hours of full load operation before leaving the factory, you can use it directly thus saving the time of test-run and expense.
2. Warranty: 12 months after installation, if our machines have any problems, you can feel free contact me, we will solve it as soon as possible, and give you the best services.
